Nascent Pipe & Tubes is a basic carrier and stockiest of the whole sorts of steel, current normal substance, and SS 317/317L Pipes & Tubes. Our start and end is by and large around evaluated and endeavored before the improvement to the clients. Our start and end is made with the faltering of the unpleasant substance and generally norms. We essentially offer a changed sort of the things as shown by the client viewpoint and rules.
SS 317/317L Pipes & Tubes are sought after with the assistance of different decisions like sorts, shape, size, width, length, thickness, conditions, adaptability, applications, finish, surface, plans, and end. These Pipes & Tubes are made with different arranged approaches like carbon, manganese, silicon, phosphorus, sulfur, chromium, nickel, nitrogen, and molybdenum. These Pipes & Tubes are made with both physical and mechanical properties like adaptability, yield strength, electrical conductivity, and warm conductivity, and electrical resistivity, modulus of progress, broadening, dissolving point, and thickness as well. These chambers are open in a couple of plans and types like CDW, ERW, solid, made, and welded as well.
Stainless Steel 317/317L Pipes & Tubes Manufacturers, Stainless Steel 317/317L Pipes & Tubes Suppliers, Stainless Steel 317/317L Pipes & Tubes Stockists, Stainless Steel 317/317L Pipes & Tubes Exporters
Stainless Steel 317/317L Pipes & Tubes Manufacturers in India, Stainless Steel 317/317L Pipes & Tubes Suppliers in India, Stainless Steel 317/317L Pipes & Tubes Stockists in India, Stainless Steel 317/317L Pipes & Tubes Exporters in India
SS 317/317L Pipes & Tubes and Cylinders are material in various the relationship, for instance, near the ocean oil entering industry, drug industry, specialty substance industry, petrochemical industry, power age industry, fertilizer industry, huge industry, paper industry, and squash industry too.These Pipes & Tubes are other than sensible for the use in a few general purposes like power exchanger, condensers, substance gear, drug equipment, seawater gear, gas making due, flight machines, food managing, shafts, siphons, turbines, and military machines too.
Stainless Steel 317/317L Pipes & Tubes Manufacturers In Mumbai, Stainless Steel 317/317L Pipes & Tubes Suppliers In Mumbai, Stainless Steel 317/317L Pipes & Tubes Stockists In Mumbai, Stainless Steel 317/317L Pipes & Tubes Exporters In Mumbai
SS 317/317L Pipes & Tubes and Cylinders make them shock attFlangesutes like machinability, welding, layered precision, formability, flexibility, strength, versatility, high versatility, and resistance from the extraordinary focus temperatures. These Pipes & Tubes are protected from the entire disintegrations, for instance, split use, stress breaking utilization, pitting disintegrating, and impact use. These chambers are made with amazing crude substance for better execution in savage circumstances. These Pipes & Tubes are made with the warming and welding process for longer value in the corrupted region. These Pipes & Tubes are especially referring to pipes for their even more extensive help life and layered accuracy. These Pipes & Tubes are phenomenally suitable for use in the planned making due.
Specification of 317/317L Stainless Steel Pipes & Tubes
Stainless Steel Pipe Specification :ASTM A312, A358 / ASME SA312, SA358
SS Tube Specification : ASTM A213, A269, A249, A511, A554 / ASME SA213, SA269, SA249, SA511, SA554
Pipe Size : 1/8” NB to 24” NB, 1/4” OD to 24” OD sizes.
Tube Size :1/2" OD to 8" OD.
Thickness Range : 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Type :Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length :Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
End Protection : Plastic Caps
Outside Finish :2B, No.4, No.1, No.8 Mirror Finish for Stainless Steel Pipes, Finish as per customer Requirements
Delivery Condition : Annealed and Pickled, Polished, Bright Annealed, Cold Drawn
Inspection, Test Reports :Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing :Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials :Sizes and Specifications other than above can be manufactured on request
Chemical Composition of Stainless Steel 317/317L Seamless Pipes & Tubes
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
|---|---|---|---|---|---|---|---|---|---|
| 317 | 0.08 max | 2 max | 1 max | 0.040 max | 0.03 max | 18 – 20 | 3 – 4 | 11 – 14 | - |
| 317L | 0.035 max | 2 max | 1 max | 0.040 max | 0.03 max | 18 – 20 | 3 – 4 | 11 – 14 | - |
Mechanical Properties Of Stainless Steel 317/317L Seamless Pipes & Tubes
| Density | 8.0 g/cm3 |
|---|---|
| Melting Point | 1454 °C (2650 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
Physical Properties of 317/317L Stainless Steel Pipes & Tubes
| Physical Properties (Room Temperature) | ||
|---|---|---|
| Specific Heat (0-100°C) | 500 | J.kg-1.°K-1 |
| Thermal Conductivity | 14.6 | W.m -1.°K-1 |
| Thermal Expansion | 16.5 | mm/m/°C |
| Modulus Elasticity | 193 | GPa |
| Electrical Resistivity | 7.4 | μohm/cm |
| Density | 7.99 | g/cm3 |
317/317L Stainless Steel Pipes & Tubes Equivalent Grades
| STANDARD | UNS | WNR. | EN | JIS |
|---|---|---|---|---|
| SS 317 | S31700 | 1.4449 | - | SUS 317 |
| SS 317L | S31703 | 1.4438 | X2CrNiMo18-15-4 | SUS 317L |
